CW-PHEB621D8 (1 Socket, 8 DIMMs, ICX)
본문
*) 특징
- Supports One(1) 3rd Intel® Xeon® processor Scalable family,250W maximum processor TDP
- Up to 8 DDR4 DIMMs, up to 2 TB total memory(dependent on memory type)
- Two(2) 1Gb-T Ethernet Controller, Optional Two(2) 10Gb-T
- 저소음 웍스테이션
Processor | : (1) 3rd Gen Intel Xeon Scalable Processor Family : Max TDP : up to 250W, Socket Type : FCLGA4189 |
Chipset | : Intel C621A |
Slots | : (4) PCI-E Gen4 x16 or (7) PCI-E Gen4 x8 |
Memory Capacity | : 8 DIMM slots supporting up to 2TB : DDR4 RDIMM/LRDIMM/LRDIMM 3DS 2933/3200 : Intel Optane DC Persistent Memory Module (DCPMM) |
| LAN | : (2) 1Gb-T ports Intel i210, Optional (2) 10Gb-T ports Intel X721 |
Graphic | : Onboard Aspeed AST2500 : Optional) Nvidia Geforce/Quadro/Tesla Graphic Controller |
| I/O Ports | : (9) SATA 6Gbs : 1 Mini-SAS HD(4P), 2 SATA 7-pin, 2 SATA DOM, 1 M.2 : (2) M.2 connectors - SATA / PCIe, supports 22110/2280/2242 : (4) USB3.2 G1 ports (@ rear) / (2) USB3.0 ports (@ front) : (1) Internal DH-10 serial Port A connector(@ internal) : (1) D-Sub 15-pin port (@ rear) : (2) 10Gb-T ports, (2) 1Gb-T ports, (1) dedicated Gb-T for IPMI |
Drive bays | : (6) 3.5" fixed + (2) 2.5" fixed |
Management | : IPMI 2.0 compliant baseboard management controller |
Power Supply | : 850 / 1000 / 1200 / 1600 / 2000W 80P Power Supply Unit |
Dimensions(H x W x D) | : 535mm x 235mm x 550mm Pedestal |
